FLKS FJFY(4Channels)SMPS Amplifier

时间:2019-6-26 13:19:39



 Story of FLKS Series FJFY: FJFY is abbreviation of Feng Jing and Fu Yan, who are also the founding members of our company. They are in charge of the warehouse and the PCB welding and play important roles in production. Their hardworking and resposibility make tremendous contributions for our company's development.
    FLKS Series FJFY four channels is the derivative product of FJFY Series two channels,which is from 4×450W-4×1300W. It is the embodiment of advanced idea and technology, and has the characteristics of low distortion, low noise ,large dynamic range and silent background, excellent clarity, high resolution and powerful low frequency regarding the tone quality. A completed protection system includes overheat protection, short circuit protection, mid-point protection and on muting protection.
   FLKS Series FJFY is applied to bars, gymnasium, night clubs, conference room and others.


Series FJFYFJFY-4450FJFY-4650FJFY-4800FJFY-41000FJFY-41300
Rated Power(8ohm)4×450W4×650W4×800W4×1000W4×1300W
Rated Power(4ohm)4×720W4×1000W4×1280W4×1600W4×2000W
Rated Power(2ohm)4×860W4×1200W4×1536W4×1920W4×2400W
Rated Power

(Bridge 8ohm)

2×1300W2×1800W2×2400W2×3000W2×3900W
Rated Power

(Bridge 4ohm)

2×1500W2×2000W2×2800W2×3600W2×4200W
Frequency Response 20Hz-20kHz:±0.1/0.3dB(1W/8Ω)
THD+N1W/8Ω<0.05
Intermodualation Distortion60Hz&7kHz 1W/8Ω
Damping Factor200:1kHz@8Ω
SNR>100dB
Slew Rate70×standard
Input Gain 20dB、23dB、26dB、29dB、32dB、35dB、38dB、41dB Optional
Input ImpedanceBalance 20k ohm   Unbalance 10k ohm
Power Supply AC~200-240V/50-60kHz
Packing Size570×595×140mm
Net/Gross Weight11.5/13.5KG15.9/17.9KG
